    GCL CTV IV Indoor Fixed HD LED Display Video Wall P0.9 P1.2 P1.5 For Power Saving Stage Installation

    Ask Lasest Price
    Brand Name : GCL
    Model Number : GTV IV
    Certification : EMC/CE/ROHS/CCC/FCC/BIS
    Price : Negotiable
    Supply Ability : 5000 Square Meter/Square Meters per Month
    Delivery Time : 15-22Days
    • Product Details
    • Company Profile

    GCL CTV IV Indoor Fixed HD LED Display Video Wall P0.9 P1.2 P1.5 For Power Saving Stage Installation

    GCL TV Indoor Fixed HD LED Display Video Wall P0.9 P1.2 P1.5 For Power Saving Stage Installation


    HD 4K, 8K Screen 16: 9 P1.9 P1.25 P1.56 Indoor LED Display Wall Rental LED Display


    Ultra HD 2K/4K

    27-inch screen, easily achieving a 16:9 golden ratio display, with ultra clear 2K/4K image stitching
    Features a wide viewing angle, allowing viewers to enjoy clear and lifelike images from different perspectives. Whether watching up close or from a distance, users can experience an exceptional visual experience.


    High Definition and High Refresh Rate for the Best Visual Experience

    Features a 16-bit high gray scale and precise color calibration system, delivering high fidelity and consistency in color.
    Capable of eliminating moiré patterns and supports HDMI/DVI/VGA/AV input interfaces.


    Die-Casting Aluminum Design

    As customers have higher requirements for LED displays, more and more cabinets have been developed to meet market demands.

    Compared with the traditional bulky cabinet, the die-casting aluminum cabinet with a humanized design is stronger, more light-weight, and precise. This LED panel is highly praised for a better user experience. The pixel pitches of this LED screen are SMD P0.9P1.25, P1.56 P1.875

    All-front Maintenance Design

    Modules, power supplies, and all other accessories can be removed from the front, making front maintenance and installation more convenient.
    The modular magnetic design allows for quick and easy maintenance.


    Ultra-thin Design:
    The casing features a die-cast aluminum design, making it very lightweight and as thin as 32mm. There’s no need for a steel structure, allowing for easy wall-mounted installation in a variety of settings.



    Parameters of Gtv IV:


    NameP0.9P1.2P1.5P1.875
    Module
    LED TypeMini09SMD1010SMD1212SMD1515
    Pixel Pitch(mm)0.931.251.561.875
    Module Resolution160*180120*13596*108160*90
    Module Size(mm)150*168.75150*168.75150*168.75300*168.75
    Scan Method1/36s1/27s1/27s1/54s
    Cabinet
    Unit Resolution4*24*24*22*2
    Cabinet Resolution640*320480*270384*216320*180
    Cabinet Size(mm)600*337.5*63
    Cabinet Area(㎡)0.2025
    Cabinet MaterialProfile Aluminum
    CabinetWeight7.5kg
    Densiy (pixels/㎡)1137777640000409600284444
    Protection LevelIP31
    Optics
    Brightness(nits/㎡)≥600nits
    CalibrationSupport Single-dot Calibration
    Color Temperature3000-10000K Adjustable
    Viewing AngleH160°,V160°
    Light Decay Rate<3%
    ContrastRatio9000:1
    Grey Scale13-16bit
    Electric
    Max Power Consumption/㎡400W500W500W500W
    Average Power Consumption/㎡120W150W150W150W
    Cabinet MaintenanceFull Front Service
    Input VoltageAC100~240V(50-60Hz)
